Monel k500
Monel K500 is a precipitation-hardenable nickel-copper alloy that combines the excellent corrosion resistance characteristic of Monel 400 with the added advantage of greater strength and hardness. These amplified properties, strength and hardness, are obtained by adding aluminum and titanium to the nickel-copper base and by a thermal processing used to effect precipitation, typically called age hardening or aging.
Share This Product:
  • Introduction
  • PARAMETER
  • APPLICATION
Chemical Composition:

Ni

Cu

Al

Ti

C

Mn

Fe

S

Si

63.0-70.0

Remainder

2.30-3.15

.35-.85

.25 max

1.5 max

2.0 max

.01 max

.50 max

Typical Mechanical Properties:

Material

Form and Condition

Tensile Strength MPa

Yield Strength (0.2% Offset) MPa

Elongation (%)

Hardness Rockwell B

Alloy K 500 Rod and Bar

Cold Drawn Annealed

621-758

276-414

50-25

75-90B

Alloy K-500 Rod and Bar

Cold- Drawn Annealed and Aged

896-1310

586-827

30-20

24-35C


Standard of execution:

Form

ASTM

Rod

B 574

Plate, sheet and strip

B 575

Seamless pipe and tube

B 622

Welded pipe

B 619, B 775

Welded tube

B 626, B 751

Welding fitting

B 366

Forged or rolled pipe flange and forged fitting

B 462

Billet and bar for reforging

B 472

Forging

B 564

Characteristics of Monel K500:

Corrosion resistance in an extensive range of marine and chemical environments. From pure water to non-oxidizing mineral acids, salts and alkalis.

Excellent resistance to high velocity sea water

Resistant to a sour-gas environment

Excellent mechanical properties from sub-zero temperatures up to about 480C

Non-magnetic alloy

Applications of  Monel K-500 :

Sour-gas service applications

Oil and gas production safety lifts and valves

Oil-well tools and instruments like drill collars

Oil well industry

Doctor blades and scrapers

Chains, cables, springs, valve trim, fasteners for marine service

Pump shafts and impellers in marine service
