Stainless Steel  Slotted Pipe
Stainless Steel Slotted Pipe
List
Stainless Steel Slotted Pipe

Stainless Steel Slotted Tube with different groove sizes in round and oval/elliptical tube used for stairway project as Handrail, put the glass into the slot.This pipe is applicated in airports, subway, railway stations, shopping malls, buildings, hotels, glass handrails and other decorative works.


Materials:
300series:301,302,303,304,304L,309,309s,310,310S,316,316L,316Ti,317L,321,347,
200series:201,202,202cu,204;
400series:409,409L,410,420,430,431,440;
Others:2205,2507,2906,330,660,630,631,17-4ph,17-7ph, S31803904L,etc

Surface: satin polished 100 to 400#, mirror polished 600 to 1,000#, hairline

Share This Product:
  • SIZE
  • CHARACTERISTICS
  • PROCESS
  • PACKING


Slot size:
38.1 OD with a 25.4 x 16.5mm
42.4 OD with a 20 x 20mm
42.4 OD with a 24 x 24mm
48.3 OD with a 30 x 27mm
48.3 OD with double 30 x 27mm
50.8 OD with a 15 x 15mm
50.8 OD with double 15 x 15mm
50.8 OD with vertical Double 15 x 15mm
50.8 OD with a 38.35 x 19.05mm
60.3 OD with a 34 x 34mm
63.5 OD with a 20 x 20mm
63.5 OD with a 38.35 x 19.05mm
76.2 OD with a 25 x 25mm
80 x 40 oval with a 24 x 24mm
60 x 40 rectangular with a 24 x 24mm
Length: 6/5 meters can cut the length as client's request

Grade

C

Si

Mn

P

S

Ni

Cr

Mo

201

≤0.15

≤0.75

5.5-7.5

≤0.06

≤0.03

3.5-5.5

16.0-18.0

-

202

≤0.15

≤1.0

7.5-10.0

≤0.06

≤0.03

4.-6.0

17.0-19.0

-

301

≤0.15

≤1.0

≤2.0

≤0.045

≤0.03

6.0-8.0

16.0-18.0

-

302

≤0.15

≤1.0

≤2.0

≤0.035

≤0.03

8.0-10.0

17.0-19.0

-

304

≤0.08

≤1.0

≤2.0

≤0.045

≤0.03

8.0-10.5

18.0-20.0

-

304L

≤0.03

≤1.0

≤2.0

≤0.035

≤0.03

9.0-13.0

18.0-20.0

-

309S

≤0.08

≤1.0

≤2.0

≤0.045

≤0.03

12.0-15.0

22.0-24.0

-

310S

≤0.08

≤1.5

≤2.0

≤0.035

≤0.03

19.0-22.0

24.0-26.0

-

316

≤0.08

≤1.0

≤2.0

≤0.045

≤0.03

10.0-14.0

16.0-18.0

2.0-3.0

316L

≤0.03

≤1.0

≤2.0

≤0.045

≤0.03

12.0-15.0

16.0-18.0

2.0-3.0

321

≤0.08

≤1.0

≤2.0

≤0.035

≤0.03

9.0-13.0

17.0-19.0

-

630

≤0.07

≤1.0

≤1.0

≤0.035

≤0.03

3.0-5.0

15.5-17.5

-

631

≤0.09

≤1.0

≤1.0

≤0.030

≤0.035

6.50-7.75

16.0-18.0

-

904L

≤2.0

≤0.045

≤1.0

≤0.035

-

23.0-28.0

19.0-23.0

4.0-5.0

2205

≤0.03

≤1.0

≤2.0

≤0.030

≤0.02

4.5-6.5

22.0-23.0

3.0-3.5

2507

≤0.03

≤0.80

≤1.2

≤0.035

≤0.02

6.0-8.0

24.0-26.0

3.0-5.0

2520

≤0.08

≤1.5

≤2.0

≤0.045

≤0.03

0.19-0.22

0.24-0.26

-

410

≤0.15

≤1.0

≤1.0

≤0.035

≤0.03

-

11.5-13.5

-

430

≤0.12

≤0.75

≤1.0

≤0.040

≤0.03

≤0.60

16.0-18.0

-

All our products are packed, stored, transported according to the international regulation.
The tubes are wrapped with anti-rust paper and steel rings to prevent damage. Identification labels are tagged according to standard specification or customer's instructions. Special packing is available as per customer's requirement.
Plus, ply wooden box are available for special protection. Other kinds of packing can be offered if request.
